I will do pcb layout design, circuit schematic and pcb board design
PCB design, Convert Schematic to PCB layout, Hindi typing, Data entry
Over deze dienst
I convert the schematic/circuit diagram into a PCB layout. I will create a custom or Prototype PCB design and PCB board Layout for your electronic work and projects for fabrication ready.
I am an Electronic Engineer. I can create Schematic diagram from scratch or Modification of schematic/circuit diagram.
Circuit designing and PCB layout designing is my work interest. I have experience in schematic diagram creation, PCB board layout, and Circuit Simulation. I work with both Analog and Digital Electronics. I can create a professional quality PCB Layout and PCB board layout as your requirement.
You need to Just send your schematic diagram (or image of hand drawn) for PCB.
I will provide
- PCB Layout
- TOP, Bottom, Silk Layer in PDF or PNG
- Schematic for PCB
- Gerber files of PCB
- Bill Of Materials (BOM)
- 3D Models Picture of PCB board
- Project file
Software use :
For PCB designing I Mostly Use Easyeda but I can also use other software
- Kicad
- Eagle
- Proteus
Field of Interest
- Circuit designing
- PCB Layout design
- PCB Editing using Gerber File
- Schematic diagram creation
- Simulation
- Digital and Analog electronics
- Troubleshooting
You can check work samples on my site- https://rb.gy/fw7kq
Specialisatie:
Circuit design
•
Schema's
•
Lay-out
•
Gerber
Bestandsformaat:
Gerber
•
BRD
•
SCH
•
3DS
•
Software:
Eagle CAD
•
EasyEDA
•
KiCad
•
Proteus
Interface:
HDMI
•
I2S
•
TDM
•
UART
•
USB
•
SPI
•
BT
•
LTE
Mijn portfolio
Veelgestelde vragen
I have a circuit design, can you convert it to PCB layout
Yes, I can design the PCB layout for your project from the schematic you have provided.
What files do you need to design the PCB?
If you already have the schematic or circuit diagram ready with you, then you can send it to me to get started. It will be helpful if you have the source file otherwise you can also send me the circuit diagram in PDF or Image format and I can make the schematic to design the PCB.
What files you will provide me and what do I do with that?
o manufacture the PCB all you need is the GERBER file, a zip file that you can send to any PCB manufacturer to fabricate the PCB and the schematic to hand solder the components. If you want to assemble it professionally, you will additionally need Bill of materials (BOM).
What specifications do you need to design the PCB?
Please mention the shape of the PCB and the required dimension. Most of the general purpose PCB is either rectangular or round shaped but if it's a custom shaped and there are mounting holes and cutouts mention that as well. And also the components are surface mount (SMT) or through hole (THT) type.
