I am a professional draftsman with 20+ years of experience specializing in joinery, furniture, and fit-out shop drawings. I produce accurate, fabrication-ready AutoCAD drawings with clear details that meet consultant and construction standards.
What I Offer
• Joinery & furniture shop drawings
• Fit-out and architectural detailing
• Plans, elevations, sections, and details
• AutoCAD Xref management for large projects
• Drawing coordination with MEP and structural layouts
Why Choose Me
✓ Fast and reliable turnaround
✓ Clean, well-layered CAD files
✓ Organized Xref structure
✓ Easy communicat
